Bosch Rexroth AGTS 2plus 4.1 4–13
00012755.eps
l
T
b
T
a
KE 2/O-180
b
T
1)
l
T
2)
a Nr./No./N°
[mm] [mm] [mm]
160
160; 240 90; 135
3 842 999 726
240
160; 240; 320 90; 135 l
T
= … mm
320
240; 320; 400 90; 135 b
T
= … mm
400
320; 400 90; 135
Kurven · Curves · Courbes
3 842 531 138 (2011.04)
Kurve KE 2/O‑180
KE 2/O‑180 curve
Courbe KE 2/O‑180
1)
b
T
= Track width in direction of transport
2)
l
T
= Length in direction of transport
1)
b
T
= Spurbreite in Transportrichtung
2)
l
T
= Länge in Transportrichtung
1)
b
T
= Ecartement de voie en direc. du transport
2)
l
T
= Longueur en direction du transport
