Bosch Rexroth AGTS 2plus 4.1 5–17
b
Q
b
L
v
N
U, f AT Nr./No./N°
[mm] [mm] [m/min]  11-122
160 160
1)
, 240, 320 0; 6 12; 15; 18 S; K 3 842 999 888
240 160
1)
, 240, 320, 400 0; 6 12; 15; 18 S; K b
Q
= … mm
320 160
1)
, 240, 320, 400 0; 6 12; 15; 18 S; K b
L
= … mm
400 240, 320, 400, 480 0; 6 12; 15; 18 S; K v
N
= … m/min
480 320, 400, 480 0; 6 12; 15; 18 S; K U = … V
640 400, 480 0; 6 12; 15; 18 S; K f = … Hz
800 400, 480 0; 6 12; 15; 18 S; K AT = …
00012789.eps
b
Q
b
L
HQ 2/S
Quertransport · Transverse conveyor · Transport transversal
3 842 531 138 (2011.04)
Hub-Quereinheit HQ 2/S
HQ 2/S lift transverse unit
Unité de levée transversale HQ 2/S
1)
Nicht geeignet für Strecken ST 2/B-100,
ST 2/C-100 und ST 2/R-100.
1)
N’est pas adapté pour les sections
ST 2/B-100, ST 2/C-100 et ST 2/R-100.
1)
Not suitable for conveyor sections
ST 2/B-100, ST 2/C-100, and ST 2/R-100.
