RF SOLUTIONS PRO TRAP Series - Page 9

Professional Radio Control
DS-PROTRAP-4
Technical Specifications
Transceiver : 725-TRX
Dimensions: 136 x 78 x 42 mm
Storage Temperature: -10 to +70
o
Celsius.
Operating Temperature: -10 to +50
o
Celsius.
Input Module: 725-IP
Dimensions: 68 x 78 x 42 mm
Storage Temperature: -10 to +70
o
Celsius.
Operating Temperature: -10 to +50
o
Celsius.
Output Module: 725-OP
Dimensions: 136 x 78 x 42 mm
Storage Temperature: -10 to +70
o
Celsius.
Operating Temperature: -10 to +50
o
Celsius.
Notes
1. Notes The power is derived directly from 725-868
2. The relay contacts in this unit are for functional use only and must not be used for isolation purposes
ELECTRICAL CHARACTERISTICS MODE MIN TYPI-
CAL
MAX Units
Supply Voltage N/A V
Relay Rating* (230Vac) RLY 1-4 5 A(rms)
Time delay from Tx on Switch to Rx Relay
operation
FSK
LORA
30
30-
1500
mS
mS
Time delay from Tx sw relax to Rx Relay
release
FSK
LORA
30
30-
1500
mS
mS
Supply Current : Quiescent
All relays operating
12
+90
mA
mA
Electrical Characteristics Min Typical Max Units
Supply Voltage 12 32 Vdc or ac
Frequency: 869.500 MHz
RF Output Power (ERP) @ 869.50 MHz - 100 mW
Supply Current : Quiescent
All output relays operating
Watchdog relay operating
When transmitting
50
+101
+25
+95
mA
mA
mA
mA
Electrical Characteristics Min Typical Max Units
Supply Voltage N/A V
Input Impedance Ohms
Supply Current 15 mA
