TRAP Remote Controls
DS-TRAP-10 Page 9
Technical specifications
Transmitters: TRAP-Transmitter
Enclosure Rating: Standard IP65 (upgradeable to IP68)
Battery Type: 3 x AAA (supplied)
Battery Life: 2 years @ approx. 50 1/2second presses p/day
Dimensions: 90 x 54 x 27 mm
Changing the Battery: Remove the six enclosure screws. Remove 2 battery compartment screws and re-
place batteries, taking care of cables and battery polarity
25
92
6
17
Mechanical Dimensions:
(All dimensions in mm)
Electrical Characteristics Min Typical Max Units
Supply Voltage 3.3 4.5 6 V
Supply Current mA
Frequency:
869.500
918.000
MHz
FSK Deviation 868MHz
918MHz
60
500
KHz
RF Output Power (ERP) - 15.5 17 dBm
