Installation
13
Figure - 7- Typical Horizontal Direct Vent System
SUPPORT BRACKET
EVERY 3' MAX.
2, 3, OR 4"
PVC PIPE
45° TERMINAL
1"
WALL
DRAIN PAN
WATER
HEATER
FLOOR
