23
Venting
INSTALLATION INSTRUCTIONS
Venting for Direct-Vent Water Heater (cont.)
Horizontal Vent Installations
Exhaust Vent
Pipe
Air Intake
Pipe
Wall plate
Inspection
Access Panel
(Optional)
Air Intake
Pipe
Wall Plate
Inspection
Access Panel
(Optional)
Ceiling
Upward Slope
to Termination
Exhaust Vent
Pipe
Termination
Te e
Ceiling
Upward Slope
to Termination
12”-24”
(31cm-61cm)
Min 36” (91cm)
Max 20’ (6.1m)
6”-12”
(15cm - 31 cm)
36”
(91cm)
36”
(91cm)
Air intake
Exhaust
Termination Tee
AREA WHERE AIR INTAKE
IS NOT PERMITTED
12”-24”
(31cm-61cm)
