MAINTENANCE
160 07/12 Maintenance Section 5-8
© 2012 Alamo Group Inc.
MAINTENANCE
To help prevent structural damage caused by loose hardware, tighten gear case hardware
as specified. Check torque after first 8 hours of use and every 50 hours thereafter.
Inspect Blades daily for normal wear. If Blades have a notch worn into the leading worn into
the leading edge at the lower bend more than 1/2” DEEP (due to running in gravel and/or
the ground), REPLACE BOTH BLADES ON THAT CARRIER IMMEDIATELY. Failure to
replace such abnormally worn blades may lead to catastrophic failure of the blade and
ejection of the broken part with tremendous force which may cause bodily injury or death.
NOTE: Replace Blades in pairs after no more than 1/2” notch wear.
BLADE SHARPENING
When sharpening blades, grind each blade the same amount to maintain balance. Follow
original sharpening pattern as shown in Figure Mnt-R-0008. Always sharpen blades by
grinding. Always sharpen both blades at same time to maintain balance. The difference in
blade weights should not exceed 1 ounce. Unbalanced blades will cause excessive
vibration which can damage gear box bearings. Vibration may also cause structural cracks
in cutter housing. DO NOT heat and pound out edge. Do not sharpen blade to a razor edge,
but leave a 1/16” blunt edge. Do not sharpen back side of blade.
Avoid personal injury. Always block the cutter up to prevent if from falling when the blades
and/ or carrier are being serviced.
