MAINTENANCE

160 07/12 Maintenance Section 5-9

MAINTENANCE

BLADE REMOVAL

Remove locknut from blade bolt through inspection hole in deck of mower near the gearbox to remove blades

for sharpening or replacement. See Figure MntP-R-0022. Always replace nut when replacing blade bolt.

When installing blades be sure and check blade bolt pivot diameter for wear. Replace bolt if worn more than 1/

4 inch at any point. Tighten lock nut to 450 ft. lbs.
