POINT B - SETTINGS
DIP 1 (ON) BARRIER SLOWSPEEDS ADJUSTMENT IN OPENING AND CLOSING (ON)
(See Point C)
DIP 1-2 STORING/ERASING RADIO CODES FOR MOTOR CONTROL (See Point D)
DIP 1-2-3 STORING/ERASING STORING/ERASING for relay R-AUX command (point E)
DIP SWITCHES CONTROL
DIP 4 Single impulse command START and RADIO - step-by-step (ON) - automatic (OFF)
DIP 5 Enable radio system SUN/MOON (ON) - SUN-PRO (OFF)
DIP 6 NORMAL operation (OFF) - PARK operation (ON)
DIP 7 ON - photocells self-test ENABLED
DIP 8 OPEN 2 command operation in PARK mode
ON - OPEN 2 command is always enabled
OFF - OPEN 2 command works if there is no vehicle on the magnetic sensor
connected to the TLC input (Traffic light control contact opened).
DIP 9 Courtesy light management (OFF)
They work with 1 Relay card ACQ9080 or 3 Relay card ACQ9081 (If none of the optional cards
is connected, turn DIP9 to OFF).
Magnet management with 1-RELAY card ACQ9080 (ON)
DIP 10 Operation after black-out
ON - the boom arm automatically closes if not already closed.
OFF - the boom arm remains still on the point it was when blackout occurred
DIP 11 ON - 3-phase motor
OFF - 1-phase motor
DIP 12 OFF - Electromechanical limit switches welded on pc card
DIP 13 ON - Lamp with flashing light / OFF - Blinker operation with fixed power supply
TIPO MOTORE DIP 14 DIP 15 DIP 16
RAPID S 3 m OFF OFF OFF
RAPID S 4 m ON OFF OFF
RAPID N 5 m OFF ON OFF
RAPID N 6 m ON ON OFF
NORMAL OFF OFF ON
INDUSTRIAL ON OFF ON
RAPID PARK 3 m OFF ON ON
A DISPOSIZIONE ON ON ON
LED WARNINGS
DL1 PROG programming activated (red)
DL2 Barrier opening (green)
DL3 Barrier closing (red)
DL4 Opening limit switch LSO (green)
DL5 Closing limit switch LSC (red)
DL6 STOP command (NC) (red)
DL7 PHOTO 1 contact (NC) (red)
DL8 PHOTO 2 contact (NC) (red)
DL9 EDGE 1 contact (NC) (red)
DL10 PROG and RADIO (on MOLEX connector) commands (green)
DL11 TCA - automatic closure time enabled (red)
DL12 Remotes programming enabled (two colors)
DL13 P1 managed by APP (blue)
OPEN 1 OPEN 1 command (to enter) (green)
OPEN 2 OPEN 2 command (to exit) (green)
CLOSE CLOSE command (NO) (green)
START Single impulse command (NO) (green)
B.I.O Clock command (NO) (green)
OK CLOSE Confirmation of closing command (green)
TLC Magnetic sensor control for traffic light control (green)
PROBE
Engine room temperature sensor for heating the engine in particularly cold climates, up to
-30 ° C (connection to connector J3) code ACG4666.
ADJUSTMENTS
TRIMMER LOW SPEED OPEN and TRIMMER LOW SPEED CLOSE - Slow speed
regulators in opening and closing approach
Slow speed regulation is performed by acting on the LOW SPEED OPEN and LOW SPEED
CLOSE trimmers through which the output voltage across the motor is varied (turning it
clockwise increases the speed).
The deceleration is automatically determined by the limit switches at about 30° before
reaching the opening or closing limit switch.
TRIMMER TCA - Automatic closing time regulator
standard not enabled and LED DL11 OFF
(trimmer rotated completely counter-clockwise)
With this trimmer it is possible to adjust the waiting time before having automatic closing.
The automatic closing is obtained only with the barrier open as a result of the command
given by the opening commands and led DL11 ON (trimmer rotated clockwise to enable the
feature).
The pause time can be adjusted from a minimum of 2 seconds to a maximum of 2 minutes.
R-AUX - AUXILIARY RELAY CONTACT (NO)
By default this relay is set as courtesy light (max 700 W - 3 A - 230 Vac) to operate 3 minutes
at each command, with time renewal at each command.
It is possible to activate the R-AUX contact by remote control by performing the memorization
procedure described in point E.
POINT C - BARRIER SLOWSPEEDS ADJUSTMENT IN OPENING AND CLOSING
This check is meant to facilitate the installer during the start-up of the system or for any
other future controls:
1 - Turn DIP1 to ON, the red led DL1 starts blinking
2 - Press the PROG button and hold it (movement is now performed in “hold-to-run” mode,
open-stop-close-stop-open etc.). If the GREEN led DL2 is on, the boom arm opens. If the
RED led DL4 is on, the boom arm closes.
3 - Carry out the slow-down speed calibration => Turn the LOW SPEED OPEN and LOW
SPEED CLOSE trimmer to minimum => Press the PROG button and hold it => After 1
second of movement the low speed will be enabled.
CAUTION: Check that the motor has enough force to move the boom both in opening and
closing. If not, increase the value set on the trimmers until the optimal operating
condition is reached.
CAUTION: In areas subject to particularly cold temperatures, turn the trimmers clockwise
5° more than the normal value, or apply the optional probe (code ACG4666) to
heat the engine.
4 - Turn DIP1 to OFF => the red LED DL1 turns off.
During Point C procedure the safety-strip and photocells are not enabled.
POINT D - PROGRAMMING RADIO CODES FOR OPENING (1000 CODES MAX) - with radio
module ACG8069
ATTENTION: before storing the radio codes, use DIP 5 to select which transmitters to use:
DIP 5 OFF: SUN-PRO variable code transmitters can be memorized:
SUN-PRO 2CH 2-channel - red keys and white led cod. ACG6210
SUN-PRO 4CH 4-channel - red keys and white led cod. ACG6214
SUN-PROX 2CH 2-channel - red keys and yellow led cod. ACG6220
SUN-PROX 4CH 4-channel - red keys and yellow led cod. ACG6224
DIP 5 ON (default): You can store transmitters with fixed code SUN and MOON:
SUN 2CH 2-channel - blue keys and white led cod. ACG6052
SUN 4CH 4-channel - blue keys and white led cod. ACG6054
SUN CLONE 2CH 2-channel - blue keys and yellow led cod. ACG6056
SUN CLONE 4CH 4-channel - blue keys and yellow led cod. ACG6058
MOON 2CH 2-channel - black keys and yellow LED cod. ACG6081
MOON 4CH 4-channel - black keys and yellow LED cod. ACG6082
ATTENTION: it is not possible to memorize at the same time transmitters with fixed code and
transmitters with variable code.
Programming can be done only when the gate is stationary.
1 - First set DIP 1 to ON and then DIP 2 to ON. The LED DL12 flashes red for 10 seconds.
2 - Press the TRANSMITTER button (usually channel A) within the allotted 10 seconds. If
the remote is memorized properly LED DL12 blinks green and a buzzer tone confirms
the correct memorization. The 10 seconds for programming the codes are automatically
renewed, with LED DL12 which flashes red, in order to store the next transmitter.
3 - To finish programming, wait 10 seconds, or press the PROG button briefly. LED DL12
stops flashing.
4 - Re-set DIP 1 to OFF and DIP 2 to OFF.
5 - End of procedure.
ALL RADIO CODES FOR TOTAL OPENING CANCELLATION PROCEDURE
Cancellations can only be performed when gate is stationary.
1 - Set DIP 1 to ON and then DIP 2 to ON.
2 - LED DL12 flashes red for 10 seconds.
3 - Press and hold the PROG button for 5 seconds. Memory cancellation is indicated by two
To Next Page
