Richen EF453A - Wall Mounted Installation Guide

38
EN
• Insert wall plug (for concrete wall only) into the holes and secure the
bracket to the wall with six ST5×40 screws.
Ceiling
2
1
3
4
5
6
Floor
Wall
For concrete wall only
Wall mounted
• Place the wall mounting bracket in the desired position ensuring that the
bracket is leveled. Mark and drill the holes.
