DRIVE LAYOUT
B421 2 SM
1.3 DRIVE LAYOUT
1. Paper Feed Motor
2. Paper Feed Clutch
3. Feed Roller
4. Friction Pad
1.4 OVERALL ELECTRICAL CIRCUIT
B421D106.WMF
FCU
Motor
Clutch
Paper
Feed
Sensor
Paper End
Sensor
Door
Switch
CN4
CN103CN104CN105
Tray
Connection
Board
B421V107.WMF
1
2
4
3
