Interface Settings
49
2
❖ SMB Work Group
Specify the SMB work group.
Enter the group name using up to 15 characters.
"*+,/:;<>=?[\]|. and spaces cannot be entered.
Use uppercase letters for alphabet.
❖ Ethernet Speed
Set the access speed for networks.
Select a speed that matches your network environment. [Auto Select] should
usually be selected.
The default setting is Auto Select.
❖ LAN Type
When you have installed the optional IEEE 802.11b interface unit, select the
method of connection.
The default setting is Ethernet.
[LAN Type] is displayed when wireless LAN board is installed. If Ethernet and
IEEE 802.11b (wireless LAN) are both connected, the selected interface has
priority.
❖ Ping Command
Check the network connection with ping command using given IPv4 address.
If you fail to connect to the network, check the following, and then retry the
ping command.
• Make sure that "IPv4" in [Effective Protocol] is set to "Effective".
• Check that the machine with assigned IPv4 address is connected to the network.
• Check if the same IPv4 address is used for the specified equipment.
❖ Permit SNMPv3 Communictn.
Set the encrypted communication of SNMPv3.
The default setting is Encryption/Clear Text.
If you select to [Encryption Only], you need to set an encryption password for
the machine.
❖ Permit SSL/TLS Comm.
Set the encrypted communication of SSL/TLS.
The default setting is Ciphertext/Clear Text.
If you set to [Encryption Only], you need to install the SSL certificate for the ma-
chine.
❖ Host Name
Specify the host name.
Enter the host name using up to 63 characters.
❖ Machine Name
Specify the machine name.
Enter the machine name using up to 31 characters.
Reference
p.4 “Accessing User Tools”
