Ricoh Aficio MP 301SPF Service Manual

IP-Fax Troubleshooting
SM Appendix 4-25 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
11 Network bandwidth too narrow?
Request the network administrator to
increase the bandwidth.
Raise the delay level.
IPFAX SW 01 Bit 0 to 3
IP-Fax bandwidth is the same as the
DCS speed. Set IP-Fax SW00 Bit 6 to
1.
12 Remote fax cancelled transmission?
Check whether the remote fax
cancelled the transmission.
Cannot send via VoIP Gateway
Check Point Action
1 LAN cable connected? Check the LAN cable connection.
2 VoIP Gateway T.38 standard? Contact the network administrator.
3 VoIP Gateway installed correctly? Contact the network administrator.
4 VoIP Gateway power switched on? Contact the network administrator.
5
Is the IP address/host name of the
specified Gateway correct?
Check the IP address/host name.
6 Number of the specified fax correct? Check the remote fax number.
7 Firewall/NAT is installed?
Cannot breach the firewall. Send by
using another method (Fax, Internet
Fax)
8 Transmission sent manually? Manual sending not supported.
9 IP address of local fax registered? Register the IP address.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
