D454 122 SM
2.5.8 MOTORS, SENSORS BOTTOM
1. Registration Roller Release Motor
2. Jogger Fence HP Sensor
3. Fold Plate HP Sensor
4. FM6 Pawl HP Sensor
5. 1st Fold Motor
6. Positioning Roller Motor
7. Direct Send JG HP Sensor
8. Registration Roller Transport Motor
