System Service Mode
D037/D038/D040/D041 9-178 SM Appendix
Displays the previous gain value of the amplifiers on the controller for Red.
001 Last Correct Value: RE Color *ENG
[0 to 7 / 0 / 1 digit/step]
[Analog Gain Adjust]
4659
Displays the previous gain value of the amplifiers on the controller for Green.
001 Last Correct Value: GE Color *ENG
[0 to 7 / 0 / 1 digit/step]
[Analog Gain Adjust]
4660
Displays the previous gain value of the amplifiers on the controller for Blue.
001 Last Correct Value: BE Color *ENG
[0 to 7 / 0 / 1 digit/step]
4661
[Digital Gain Adjust]
RE: Red Even signal, RO: Red Odd signal
001 Last Correct Value: RE Color *ENG
002 Last Correct Value: RO Color *ENG
[0 to 1023 / 0 / 1 digit/step]
4662
[Digital Gain Adjust]
GE: Green Even signal, GO: Green Odd signal
001 Last Correct Value: GE Color *ENG
002 Last Correct Value: GO Color *ENG
[0 to 1023 / 0 / 1 digit/step]
4663
[Digital Gain Adjust]
BE: Blue Even signal, BO: Blue Odd signal
001 Last Correct Value: BE Color *ENG
002 Last Correct Value: BO Color *ENG
[0 to 1023 / 0 / 1 digit/step]
