Ricoh Aficio MP C2050 Service Manual

Jam Detection
D037/D038/D040/D041 7-4 SM Appendix
Jam Code
SP
Display Description
LCD
Display
7504 69
R-tray Paper Exit
Sensor
Paper exit sensor of the side tray does
not turn off.
W
7504 230 FIN:Paper Exit Error
The machine does not get paper exit
data from the internal finisher.
R1, R2
7504 231 FIN:Command Error
The machine gets a command error
from the internal finisher.
R1, R2
7504 240 Fin. Entrance: ON
Entrance sensor of the internal finisher
does not detect paper.
C, R1,
R2
7504 241 Fin. Entrance Sensor
Entrance sensor of the internal finisher
does not turn off.
R1, R2
7504 242 Feed-Out Belt Motor
The mainframe detects the lock signal
from the paper transport motor of the
internal finisher.
R1, R2
7504 243 Stapler Motor
The mainframe detects the lock signal
from the staple motor of the internal
finisher.
R1, R2
7504 244 Jogger Motor
The mainframe detects the lock signal
from the front or rear jogger motor of the
internal finisher.
R1, R2
7504 245
Pick-Up Roller Lift
Motor
The mainframe detects the lock signal
from the pick-up roller contact motor of
the internal finisher.
R1, R2
7504 246
Stapler Unit Drive
Motor
The mainframe detects the lock signal
from the stapler unit movement motor of
the punch unit.
R1, R2
7504 247 Output Tray Motor
The mainframe detects the lock signal
from the feed motor of the internal
finisher.
R1, R2
