15. Slide the print cartridge in horizontally. When the cartridge can go no further, raise it
slightly and push it fully in. Then push down on the cartridge until it clicks into place.
CMF021
16. Using both hands, carefully push up the front cover until it closes.
CMF022
17. Carefully pull tray 1, and then pull out with both hands.
CMF023
Place the tray on a flat surface.
