Ricoh M065 - Cleaning the Paper Dust Container; Paper Size Sensor Board

Paper Feed
M065/M066 4-106 SM
4.10.13 PAPER SIZE SENSOR BOARD
1. Inner left lower cover ( p.4-11)
2. Paper size sensor board [A] (
x 2, x 2)
4.10.14 CLEANING THE PAPER DUST CONTAINER
1. ITB unit ( p.4-38)
2. PCDU (
p.4-20)
3. Peel off the tape [A] (service parts) and clean the paper dust container [B] with a
vacuum cleaner.
