No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
764 B
Paper position sensor slide motor error
The paper position sensor moves but is not detected at the home position within the
specified time. The 1st detection failure issues a jam error, and the 2nd failure issues
this SC code.
• Motor harness disconnected, loose, defective
• Defective motor
1. Check the connections to the paper position sensor slide motor.
2. Defective paper position sensor slide motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
765 B
Paper position sensor slide motor error
The paper position sensor moves but is not detected at the home position within the
specified time. The 1st detection failure issues a jam error, and the 2nd failure issues
this SC code.
• Motor harness disconnected, loose, defective
• Defective motor
1. Check the connections to the paper position sensor slide motor.
2. Defective paper position sensor slide motor.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
766 B
Paper position sensor slide motor error
The paper position sensor moves but is not detected at the home position within the
specified time. The 1st detection failure issues a jam error, and the 2nd failure issues
this SC code.
• Motor harness disconnected, loose, defective
• Defective motor
1. Check the connections to the paper position sensor slide motor.
2. Defective paper position sensor slide motor.
3. Appendix: Service Call Conditions
90
3
