ENGLISH Load: Baby Seat Adapter (VBK0003)
VBK0003-L-Babyschalenhalter-180104.docx
Page 4 of 4
Riese & Müller GmbH | Feldstraße 16 | D-64331 Weiterstadt | Tel.: 06151-366 86-0 | Fax: 06151-366 86-20 | E-Mail: team@r-m.de | Internet: www.r-m.de
Mark the necessary positions for drilling the holes
into the bottom plate. Remove the baby seat adapter
and drill the holes with a 6mm wood drill.
Attach the adapter by using the round head bolts,
washers and self lock nuts (tightening torque 3 up to
5Nm).
Attach the baby seat.
Secure the baby seat with the rupper ropes.
If not needed, the baby seat adapter can be
removed.
See following table for a small selection of baby
seats.
