Range of Hardware
The Rievtech range of micro programmable logic controllers provides a mix of expandable and non-expandable CPUs. Packed
with powerful features, each CPU in the range can provide a good mix of analogue/digital signals for your control projects.
NOTICE:
Key for understanding lettering used in the following tables:
N = No; Y = Yes;
D = Digital only; DA = Digital or Analogue;
R = Relay 10A max. rating (2A inductive);
T = Transistor PNP 0.3A max. rating.
3.3.1. Non-Expandable CPU Range
Table 1 - PR-6 Series
Model
Expansion
Supply
Inputs
Outputs
High Speed
Count
PWM
HMI
RTC
PR-6AC-R
No
110-240
VAC/DC
4 Digital
2 Relays
(10A)
No
No
No
Yes
PR-6DC-DA-R
No
12-24 VDC
4DA 0-10V
2 Relays
(10A)
No
No
No
Yes
Table 2 - PR-12 Series
Model
Expansion
Supply
Inputs
Outputs
High Speed
Count
PWM
HMI
RTC
PR-12AC-R-E
No
110-240
VAC/DC
8 Digital
4 Relays (10A)
No
No
No
Yes
PR-12DC-DA-R-E
No
12-24 VDC
8D (4DA 0-10V)
4 Relays (10A)
No
No
No
Yes
PR-12AC-R
No
110-240
VAC/DC
8 Digital
4 Relays (10A)
No
No
Yes
Yes
PR-12DC-DA-R
No
12-24 VDC
8D (4DA 0-10V)
4 Relays (10A)
4x60kHz
No
Yes
Yes
PR-12DC-DA-TN
No
12-24 VDC
8D (4DA 0-10V)
4 T (PNP)
4x60kHz
4x10kHz
Yes
Yes
3.3.2. Expandable CPU Range
Table 3 - PR-14 Series
Model
Expansion
Supply
Inputs
Outputs
High Speed
Count
PWM
HMI
RTC
PR-14AC-R
Yes
110-240
VAC/DC
10 Digital
4 Relays
(10A)
No
No
Yes
Yes
