Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000 User Guide 2-63
Table 2-51 Average Count for TOI Measurement
Parameter
Remarks
Default
10
Range
1 to 1,000
Unit
None
Knob Step
1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
1
2. Avg Mode
Sets the average mode to "Exponential" or "Repeat". The default average mode
is "Exponential".
⚫ When "Exponential" is selected, the result is the exponential average of the
measurement results obtained in the past N times (N is specified in "Avg
Number").
⚫ When "Repeat" is selected, the result is the arithmetic average of the
measurement results obtained in the past N times (N is specified in "Avg
Number").
3. Avg State
Selects whether to averaging the measurement results. By default, it is set to
"On".
4. TOI Span
This span is consistent with the span of the spectrum analyzer. It refers to the
frequency range of the sweep. After it is set, the span of the spectrum analyzer
will be modified accordingly. You can use the numeric keys, the knob, or arrow
keys to modify this parameter; you can also use the touch screen to modify the
parameter.
Table 2-52 Span for TOI Measurement
Parameter
Remarks
Default
2 MHz
Range
100 Hz to 4.5 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step
TOI distortion span/100,
Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
Note
[1]
: If option RSA3000-BW1 is installed, the available range is from 10 Hz to 4.5 GHz.
For details about the Auto Couple and Meas Preset menus, refer to their
descriptions on Page 2-44.
