Chapter 1 Quick Start RIGOL
RSA3000 User Guide 1-13
signal.
CAUTION
To avoid damaging your hearing, please turn the volume down
to zero first and then gradually turn the volume up after
putting on the earphone.
3. Gen Output 50Ω
The output of the tracking generator can be connected to a receiver through a
cable with an N male connector. This function is only available for
RSA3045-TG/RSA3030-TG.
CAUTION
To avoid damage to the tracking generator, the reverse power
cannot exceed +10 dBm when the frequency is lower than 10
MHz; the reverse power cannot exceed +20 dBm when the
frequency is greater than 10 MHz. The reverse DC voltage
should not exceed 50 V.
4. RF Input 50Ω
The input terminal of the signal under test. [RF Input 50Ω] can be connected
to the device under test (DUT) via a cable with an N male connector.
CAUTION
For the signal input to the RF input terminal, ensure that the
DC voltage component and the maximum continuous power of
the AC (RF) signal component do not exceed 50 V and +30
dBm to avoid damaging the instrument.
