RIGOL Chapter 2 Functions of the Front Panel of GPSA
2-46 RSA3000 User Guide
Table 2-32 Average Count of ACP Measurement
Parameter
Remarks
Default
10
Range
1 to 1,000
Unit
None
Knob Step
1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
1
2. Avg Mode
Sets the average mode to "Exponential" or "Repeat". The default average type is
"Exponential".
⚫ When "Exponential" is selected, the result is the exponential average of the
measurement results obtained in the past N times (N is specified in "Avg
Number").
⚫ When "Repeat" is selected, the result is the arithmetic average of the
measurement results obtained in the past N times (N is specified in "Avg
Number").
3. Avg State
Selects whether to averaging the measurement results. By default, it is set to
"On".
4. Main Chan BW
Sets the bandwidth of the main channel, and the power of the main channel is
the power integral within this bandwidth. You can use the numeric keys, the
knob, or arrow keys to modify this parameter; you can also use the touch screen
to modify the parameter.
Table 2-33 Main Channel Bandwidth for ACP Measurement
Parameter
Remarks
Default
2 MHz
Range
[1]
33 Hz to 1.5 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step
main channel bandwidth/100, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
Note
[1]
: If option RSA3000-BW1 is installed, the available range is from 3 Hz to 1.5 GHz.
5. Adj Chan BW
Sets the frequency width of the adjacent channels.
⚫ The adjacent channel bandwidth is related to the main channel bandwidth,
and the settable range is from (main channel bandwidth/20) to (main
channel bandwidth x 20).
⚫ You can use the numeric keys, the knob, or arrow keys to modify this
