10 |
Fan mode
This mode uses the fan to circulate air without changing the room temperature. In this mode swing
operations for air direction can still be adjusted. In FAN mode you can’t set the temperature, so no
temperature will display on the remote.
1. Select FAN mode
2. Select the fan speed
3. Turn on the unit
Setting the timer
The timer function works by adding a time after which the timer will come
on and then be switched o. When setting, the time will increase by 30
minute increments with each press, up to 10 hours. After 10 hours and
up to 24 hours it will increase in 1 hour increments. For example, press 5
times to get 2.5 hours, and press 10 times to get 5 hours. The timer will
revert to 0.0 after 24 hours.
Cancel either function by setting the timer to 0.0 hours.
1. Press TIMER to initiate the ON time sequence.
2. Press the up or down button multiple times to set the desired time to
turn on the unit.
3. Wait one second, the timer ON will be activated.
4. Press TIMER to initiate the OFF time sequence.
5. Press the up or down button multiple times to set the desired time to turn o the unit.
6. Wait one second, the timer o will be activated.
If the timers are set correctly the timer on / o icons will display on the remote, refer image above.
Timer on / o setting example
Remember that the time periods you set for both functions refers to the hours AFTER the current
time. In the below example once the timer button is selected (at 1pm), the timer will come on 2.5
hours later, and turn o 5 hours later.
MODE
ON/OFF
M
ODE
F
AN
SHORT
CUT
TIMER ON
TIMER OF
F
T
EMP
S
L
E
EP
1sec
TIMER
x5
ON/OFF
M
ODE
F
AN
SHORT
CUT
TIMER ON
TIMER OF
F
TEMP
S
L
E
EP
1sec
x10
TIMER
ON/OFF
M
ODE
F
AN
SHORT
CU
T
TI
M
E
R
O
N
TIMER OF
F
TEMP
S
L
E
EP
ON/O
FF
MODE
F
AN
SHOR
T
CUT
TI
M
E
R
O
N
TIMER OF
F
TEM
P
S
L
E
EP
TIMER
TIMER
Current
time 1pm
3:30pm 6:00pm
Timer starts Unit turns on Unit turns o
2.5 hours later
5 hours later
