Rinnai REU-VRM3237WC Service Manual

Infinity REU-VR3237WG / HD250e REU-VRM3237WC - 37 - Issue 1 - 19/05/09 ©Rinnai
21. Parts List
(IIHFWLYH
REU-VRM3237WG / REU-VRM3237WC
NO DESCRIPTION RA CODE 11 DIGIT CODE VR3237WG VR3237WG-50 VRM3237WC
1 OUTER CASE EURO WHITE 92093832 014-438-000 1 1
1 OUTER CASE TITAN METALLIC 92093831 014-439-000 1
2 HEAT PROTECTION PLATE 030-941-000 1 1 1
4 PANEL FRONT EURO WHITE 92099926 019-4018000 1
4 PANEL FRONT EURO WHITE 92099928 019-4019000 1
4 PANEL FRONT TITAN METALLIC 92099930 019-4020000 1
7 BRKT WALL 92093377 106-329-000 22 2
10 SEAL PANEL FRONT TOP 92086909 580-453-000 1 1 1
11 SEAL PANEL FRONT SIDE 92086917 510-903-000 22 2
12 CONNECTION REINFORCEMENT PANEL
044-154-000 1 1 1
13 BAG FOR INSTALLATION
MANUAL 600-051-000 1 1 1
14 SEAL PACKING 510-893-000 1 1 1
15 INF20 CABLE ENTRY (NEW) 92073352 106-104-000 1 1 1
16 SEAL HARNESS EASY CONN 92099984 580-0105000 22 2
18 REINFORCEMENT PLATE 044-151-000 1 1 1
23 HARNESS EASY CONN 92099986 106-641-000 1 1 1
24 CABLE ACCESS BRACKET 538-840-000 1 1 1
100 INLET GAS 3/4 92081587 106-290-000 1 1 1
101 SCREW TEST POINT 92099956 501-275-005 22 2
102 GAS CONTROL 92086926120-241-000 1 1 1
103 MANIFOLD LP
92095036 101-701-000 1 1 1
103 MANIFOLD
NG 92095035 101-702-000 1 1 1
104 BURNER ASSY NG 92092213 000-140-000 1 1 1
104 BURNER ASSY LP 92099932 000-160-000 1 1 1
105 DAMPER NG 92099934 140-775-000 1 1 1
105 DAMPER LP 92099936 140-788-000 1 1 1
107 BURNER CASE BOTTOM PLATE 004-564-000 1 1 1
108 BURNER CASE FRONT 098-985-000 1 1 1
109 PACKING 580-573-000 1 1 1
110 LEAN AND RICH BUNSEN BURNER ASSEMBLY 157-090-000 22 22 22
111 BURNER CASE BACK PANEL 098-986-000 1 1 1
113 COMBUSTION CHAMBER FRONT PLATE 019-3389000 1 1 1
114 COMBUSTION CHAMBER FRONT PLATE PACKING 580-574-000 1 1 1
115 ELECTRODE 92086974 202-156-000
1 1 1
116 ELECTRODE FR 92093640 2
30-057-000 1 1 1
117 PACKING ELECTRODE 92087015 580-0390000 1 1 1
118 ELECTRODE HOLDER RH 92087006 580-505-000 1 1 1
121 SLEEVE ELECTRODE 92087030 518-035-000 1 1 1
122 SOLENOID VALVE COVER 098-0647000 1 1 1
123 UPPER COMBUSTION CHAMBER PACKING 092-046-000 1 1 1
124 LOWER COMBUSTION CHAMBER PACKING 092-047-000 1 1 1
125 HEAT EXCHANGE ASSEMBLY 92087049 314-696-000 1 1 1
131 EXHAUST FLUE 92095934 055-510-000 1 1 1
132 GASKET INNER FLUE 92096445 580-576-000 1 1 1
133 GASKET OUTER FLUE 92096452 580-681-000 1 1 1
150 FAN COMB 92095022
222-534-000 1 1 1
151 FAN CASING 9
2098862 035-867-000 1 1 1
153 FAN CONNECTING BRACKET 106-649-000 1 1 1
154 GASKET FAN 92099942 580-580-000 1 1 1
400 INLET WATER 3/4 92099968 333-301-NPB 1 1 1
401 PLUG BAND 553-119-000 1 1 1
402 FILTER WATER LARGE 92083773 196-062-000 1 1 1
