Rinstrum C510 User Manual

Name Address Type R W Description
Primary units, dp,
resolutions
0306
H
uint32 A N 32 bit number containing units, decimal
point location and resolution index for all
three ranges. Bits are as follows:
0-3: Decimal point
4-7: Units
8-15: Resolution index 3
16-23: Resolution index 2
24-31: Resolution index 1
See E1 setting under Section 5.2 for
resolution values.
Secondary units, dp,
resolutions
0307
H
uint32 A N 32 bit number containing units, decimal
point location and resolution index for all
three ranges. Bits are as follows:
0-3: Decimal point
4-7: Units
8-15: Resolution index 3
16-23: Resolution index 2
24-31: Resolution index 1
See E1 setting under Section 5.2 for
resolution values.
Tertiary units, dp, resolutions 0308
H
uint32 A N 32 bit number containing units, decimal
point location and resolution index for all
three ranges. Bits are as follows:
0-3: Decimal point
4-7: Units
8-15: Resolution index 3
16-23: Resolution index 2
24-31: Resolution index 1
See E1 setting under Section 5.2 for
resolution values.
Comms Start 0309
H
execute N A Dummy register. Executing does nothing.
Init function 030B
H
execute N A Re-initialise after changing settings. Use
an argument of 1 to re-init setpoints and
IOs
User Number 1 0310
H
int32 A A User readable/writable number 1
User Number 2 0311
H
int32 A A User readable/writable number 2
User Number 3 0312
H
int32 A A User readable/writable number 3
User Number 4 0313
H
int32 A A User readable/writable number 4
User Number 5 0314
H
int32 A A User readable/writable number 5
User Number 1 Name 0316
H
string A A Menu name for user readable/writable
number 1 (register 0x0310). If set, user
number 1 will appear in the operator
menus under this menu name.
User Number 2 Name 0317
H
string A A Menu name for user readable/writable
number 2 (register 0x0311). If set, user
number 2 will appear in the operator
menus under this menu name.
User Number 3 Name 0318
H
string A A Menu name for user readable/writable
number 3 (register 0x0312). If set, user
number 3 will appear in the operator
menus under this menu name.
84 C500-600-2.0.3
