5
Take a minute to make sure you have everything you need.
Note: Do not proceed with assembly if any parts are missing.
The part code is stamped on each connector. Profiles are listed in order by size, largest to smallest. Panels are
identified with stickers.
Exact dimensions can be found in the packing list.
The drawings in this manual are designed for the greenhouse owner who has purchased a GH44, which
consists of one front unit (GH40A), one back unit (GH40B) and . If you have purchased additional modules the
instructions are indicated in the text.
Part Code GH44 GH46 GH48 Description
01444Corner Frame Connector
2D 11 15 19 Frame Connector
15111Doorway Frame Connector
3A222Left Rib Connector
4A222Right Rib Connector
5A 15 25 35 Rib Connector
6A222Left Pediment Connector
7A222Right Pediment Connector
8A222Top Pediment Connector
09 10 10 10 T-Oval Connector
10333Oval Junction Connector
B2 16 20 24 Base Profile (50 cm, 1' 7M")
18
18D
4
4
4
4
4
4
Corner Oval Connector
Corner Oval Connector (Door)
Door44111Upper Door Lintel (1290 cm, 4’2C”)
PS1”/14444Inner Door Latch Screw
Door22222Bottom Door Hinge
DoorH2222Inner Door Latch
