Prepare Your Parts for Assembly
Remove everything from your packages and sort them according to part type. Since
assembly is done from taking parts from every box, it is best to put everything together.
The boxes are printed with a ruler to help you distinguish between profiles.
Note: Protect unassembled panels from the sun to prevent identification stickers from adhering to the glazing.
DSN111Door Sealer (roll)
GF111Flexible Glazing Seal (roll)
RA1468RA Glazing Element (57.3 cm, 1' 10L")
RB4 6 10 14 RB Glazing Element (84.8 cm, 2' 9E")
RB6444RB Glazing Element (80 cm, 2' 7A")
RB1101418RB Glazing Element (52 cm, 1' 8A")
RC5101418RC Glazing Element (95.5 cm, 3' 1F")
RC1101418RC Glazing Element (66.6 cm, 2' 2B")
RC3468RC Glazing Element (58 cm, 1' 10N")
RD1 16 24 32 RD Glazing Element (56.9 cm, 1' 10E")
PIN1357Connector Pin (packages)
GT1222Pin and Glazing Tool
SF111Soft Foam Roof Insulation (roll)
SUPP1 357Roof Reinforcement Kit (Packets)
AS 706 1014Cable screw
AW5111Allen Wrench
Hook1357Top Catch
CAB40357Cable
Part Code GH44 GH46 GH48 Description
