68
Measurement in FFT Mode
Setting the FFT scale type
Make the setting for the FFT scale (Y axis scale) with the [FFT Scale] item
in the [Display] menu.
• Log: Logarithmic scale
• Linear: Linear scale
Setting the cursor X axis unit
1. At the [Display] menu screen, select [X Unit] and press the ENT
key.
2. Use the / keys to select [Hz], [kcpm], or [odr], and press the
ENT key.
• Hz: Hertz
• kcpm: Kilo Cycles per Minute
• odr: Set reference frequency (order).
3. When [odr] was selected, you should set the reference frequency
using one of the two methods described below.
Method 1
Select [Standard Frequency] and enter the value by direct edit.
Method 2
(1) At the graph screen, move the cursor to the frequency you
want to set.
(2) Select [odr] for [X Unit] in the [Display] menu.
(3) Press the STORE key.
To Next Page
