14
1 030-5993 Cylinder, Tie-Rod, 2-1/2" X 6"
2 030-5967 40THC12-175, 3/4” ORB Ports @ 90°
3 105-0013 Left Walking Arm Weldment, shown
* 105-0014 Right Walking Arm Weldment
4 105-0015 Walking Arm Hook Weldment
5 105-0016 Centre Axle Weldment c/with Bolt In Spindles
6 105-0035 Centre Axle Lower Link Weldment (x2)
7 105-0036 Centre Axle Upper Link Weldment (x2)
8 105-0074 Centre Axle Pin Weldment, Ø1-1/2” x 11” Useable, Tapped 3/4”, NC, Pltd.
9 105-0078
Walking Arm Pin Weldment, Ø1-1/2” x 8-1/4” useable
10 105-0087 Cylinder Pin Weldment, Pltd. Ø1” x 4-5/16” Useable
11 200-6011-1 812 Hub c/w Cups (CTD), Refer to Page 59 for Details
12 202-6013 Dust Cap - DC 17 (CTD)
13 203-6044 Ø2-1/2” 812 Spindle - Bolt-In, 11-3/4” Long
14
Varies
Refer to Section 2 page 25
15
Varies
Refer to Section 2 page 25
16 419-0004 1/4 NF Grease Zerk, Straight, Pltd.
17 419-0006 1/4 NF Grease Zerk, 90°, Pltd.
18 526-0622 3/8” x 2-3/4” Capscrew, NC, Gr.5, Pltd.
19 526-0824 1/2” x 3” Capscrew, NC, Gr.5, Pltd.
20 526-0932 9/16” x 4” Capscrew, NC, Gr.5, Pltd.
21 526-6103 3/8” Stover Lock Nut, NC, Gr.B, Pltd.
22 526-6105 1/2” Stover Lock Nut, NC, Gr.B, Pltd.
23 526-6109 1” Stover Lock Nut, NC, Gr.B, Pltd.
24 526-6112 9/16” Stover Lock Nut, NC, Gr.B, Pltd.
25 526-7308 1/2” Stover Lock Nut, NC, Gr.C, Pltd.
26 530-0744 1/2” x 4” Capscrew, NC, Gr.8, Pltd.
27 530-1250 3/4” x 2” Capscrew, NC, Gr.8, Pltd.
28 530-1672-7.5 1” x 9” Capscrew, NC, Gr.8, Pltd. (cut to 7.5)
29 543-5563 9/16” Wheel Nut, NF, Gr.5, Pltd.
30 550-5205 5/16” Flat Washer, Pltd.
31 550-5212 3/4” Flat Washer, Pltd.
32 550-5216 1” Flat Washer, Pltd.
33 550-5307 1/2” SAE Flat Washer, Pltd.
34 550-5316 1” SAE Flat Washer, Pltd.
35 550-5615 9/16” SAE Flat Washer, Gr.8, Pltd
36 551-5012 3/4” Spring Lock Washer, Pltd.
37 556-0906 3/16” x 1-3/4” Cotter Pin, Pltd.
38 560-1614 1” x 3-1/2” OD Cylinder Pin , Pltd.
39 827-0089 Walking Arm Linkage Pin, Ø1-1/2” x 17”, Useable
40 827-0090 Knuckle Pin, Ø1-1/2” x 16-5/8, Pltd.
41 839-0074 Lower Centre Axle Link Arm Painted
To Next Page
