33
MONARCH PART NUMBER 648381
RITE WAY PART NUMBER 030-5967
1 492680 Clevis Cap, 4” - 3/4” ORB @ 90º, 1” Cyl. Pin
2 492695 Rod Cap, 4” - 1-3/4” ID, 3/4” ORB
3 294033 Piston, 4”- 1-1/8” TH / TP - Cast
4 194897 Seal Hallite 605 Rod, Ø1-3/4”
5 467312 Cylinder Tube, 4” x 12”
6 492342 Tie Rod, 5/8” x 12”
7 134953 Cylinder Pin, 1” x 3.37 for HP / COT
8 135995 Cotter Pin, 3/16” x 1-1/2”, Pltd.
9 148000 Set Screw, NF, 3/8” x 5/16”, Pltd.
10 493168 Rod Clevis, 1-1/2” x 1” - Short / N
11 128271 Hex Nut, 5/8” , NF, Gr.5, Painted
12 186562 Plug, 3/4” NF, Socket Head c/with O-ring
13 130559 Hex Nut, 1-1/8”, NF, Lock GRB
14 649229 Seal Kit, RK 40H-175 Lion Hyd. Rep. Kit
