Riviera LEVANTE - Page 2

Front Panel and Connections
Rear Panel and Connections
www.rivieralabs.com
info@rivieralabs.com
GENERAL POWER SWITCH
IEC CONNECTOR
FUSE
Remote
VOLUME CONTROL
NIGHT SWITCH
HEADPHONE SWITCH
INPUT SELECTOR
VOLUME CONTROL
SPEAKERS OUTPUT
BALANCED INPUTS
POWER SWITCH
CLASS A / CLASS AB SELECTOR
UNBALANCED INPUTS
HEADPHONE OUTPUT
When you move the Class A / Class AB selector the unit turns off for 6 seconds (the selected
Class LED blinks).
GROUND
IR RECEIVER
