8.1 Continuous and Multi-scan modes
In the Continuous Mode, an additional data analysis screen displays:
# Decodes 013/019
% Decodes 068%
There is a limit of 100 good scans in the Continuous Modeor 250 total scans—whichever comes first.
When a limit is reached, the unit automatically stops scanning.
In continuous mode the unit continues to attempt reads as long as the trigger is depressed. When using this
mode the beam may be moved around the symbol to provide extra analysis. The analysis result is based on
the average.
When multi-scans are selected the number of remaining scans needed to complete the analysis is displayed:
*0192837465*
03 Scans Remain
After the last scan a double beep or chirp will signal completion of the scan. The resulting analysis is an
average of the scans.
13 good decodes out of
19 attempted reads
Percentage of good reads
