Model D4000 SP1 Inspector
TM
Operator’s Guide
RJS, Minneapolis, MN 002-5572
iv
TABLE 1 (CODE IDENTIFIERS D4000 SP1 ) 16
TABLE 2 (IDENTIFIER DESCRIPTIONS FOR PASS/FAIL ANALYSIS SCREENS) 16
8.0 DATA ANALYSIS SCREENS 18
ACCEPTABLE 20
WARNING 20
REJECTED 20
TABLE 3 (LED, BARCODE WIDTH DEVIATIONS) 21
8.1 CONTINUOUS AND MULTI-SCAN MODES 22
9.0 CONNECT TO OTHER DEVICES 23
CONNECT TO COMPUTER 23
CONNECT TO PRINTER 23
CONTACT RJS FOR DETAILS: 23
APPENDIX A (CODE 128) 24
CODE 128 24
DISPLAY OF CODE 128 (RULES) 24
TABLE A-1 (CODE 128 — SUBSET A) 27
TABLE A-2 (CODE 128 — SUBSET B) 28
TABLE A-2 (CODE 128 — SUBSET B) 28
TABLE A-3 (CODE 128 — SUBSET C) 29
USS SHIPPING CONTAINER CODE (CASE CODE 128) 30
APPENDIX B (CODE 93) 31
CODE 93 31
TABLE B-1 (CODE 93 CHARACTER SET) 32
APPENDIX C (BATTERY DISPLAYS) 33
BATTERY DISPLAYS 33
APPENDIX D (MAGNIFICATIONS) 34
UPC/EAN MAGNIFICATIONS & BAR WIDTH DEVIATIONS 34
APPENDIX E (PRINT FUNCTIONS) 35
PRINT FUNCTIONS 35
PRINTOUT OPTIONS 35
ANALYSIS 35
STORAGE 35
FIGURE E-1 (CONTINUOUS SCAN) 36
FIGURE E-2 (MULTI-SCAN) 36
