RM 40 - List of Components

Mod 40 4.00
date 07-11-2002 Page 2 di 2
List of components
C 1 = 180 pF 50 V N750
C 2 = 180 pF 50 V N750
C 3 = 220 pF 50 V N750
C 4 = 10 nF 50 V
C 5 = 10 µF 25 V
C 6 = 10 nF 50 V
C 7 = 10 nF 50 V
C 8 = 33 pF 50 V N750
C 9 = 180 pF 50 V N750
C 10 = 270 pF 50 V N750
C 11 = 100 pF 50 V N750
R 1 = 330 Ω ¼W
R 2 = 68 Ω 2W
R 3 = 68 Ω 2W
R 4 = 2,2 KΩ ¼W
D
1 = 1N4148
D 2 = 1N4148
D 3 = 1N4007
D 4 = 1N4148
D 5 = 1N4148
MSFT1 = MOS RM3
Fuse = 5A
P 1 = Switch
L 1 = 7 turns φ 5 mm wire φ 0,8 mm
L 2 = 17 turns φ 7 mm wire φ 0,63 mm
L 3 = 6 turns φ 5 mm wire φ 0,8 mm
L 4 = 12 turns φ 5 mm wire φ 0,8mm
