RM KLV 1000 - List of Components

Mod KLV 1000 3.01
List of components
date 04-01-2002 Page 3 di 4
C 1 = 100 µF 450 V
C 2 = 100 µF 450 V
C 3 = 100 µF 450 V
C 4 = 100 µF 450 V
C 5 = 100 nF 50V
C 6 = 2200 µF 16 V
C 7 = 2,2 nF 1500V
C 8 = 22 nF 1000 V polyester
C 9 = 2,2 nF 1500 V
C 10 = 2,2 nF 1500 V
C 11 = 2,2 nF 1500 V
C 12 = 2,2 nF 1500 V
C 13 = 2,2 nF 1500 V
C 14 = 2,2 nF 1500 V
C 15 = 100 nF 50V
C 16 = 150 pF 500 V N750
C 17 = 100 nF 50V
C 18 = 150 pF 500 V N750
C 19 = 150 pF 500 V N750
C 20 = 100 nF 50V
C 21 = 150 pF 500 V N750
C 22 = 100 nF 50V
C 23 = 100 nF 50V
C 24 = 470 µF 50 V
C 25 = 100 nF 50 V
C 26 = 100 nF 50 V
C 28 = 2,2 nF 1500 V
C 29 = 2,2 nF 1500 V
C 30 = 22 pF 500 V N750
C 31 = 22 pF 500 V N750
C 32 = 100 nF 50 V
C 33 = 100 nF 50 V
C 34 = 220 pF 500 V N750
C 35 = 220 pF 500 V N750
C 36 = 100 nF 50 V
C 37 = 150 pF 500 V N750
C 38 = 100 nF 50 V
C 39 = 470 µF 50 V
C 40 = 100 nF 50 V
C 41 = 100 pF 50 V N750
C 43 = 470 pF 50 V N750
C 44 = 100 nF 50 V
C 45 = 2,2 pF 50 V N750
C 46 = 33 pF 50 V N750
C 47 = 100 nF 50 V
C 48 = 100 nF 50 V
C 49 = 68 pF 500 V N750
C 50 = 68 pF 500 V N750
C 51 = 10 nF 50V
C 52 = 27 pF 50 V N750
C 53 = 10 nF 50V
C 54 = 10 nF 50V
C 55 = 33 pF 50 V N750
C 56 = 10 nF 50V
C 57 = 100 nF 50V
C 58 = 8,2 pF 50 V N750
C 59 = 10 µF 16V
C 60 = 47 µF 16V
C 61 = 330 µF 16V
C 62 = 10 nF 50V
C 63 = 10 µF 16V
C 68 = 27 pF 50 V N750
C 72 = 470 nF 630 V~
C 73 = 100 nF 50V
Cv 1 = Variable condensator 30 pF
Cv 2 = Variable condensator 50 pF
Cv 3 = Variable condensator 350 pF
Cv 4 = Trimmer 10 - 100 pF
R 1 = 2,2 ΚΩ 15W
R 2 = 470 KΩ 2W
R 3 = 47 Ω 5W
R 4 = 47 Ω 5W
R 5 = 47 Ω 5W
R 6 = 47 Ω 5W
R 7 = 1,0 ΚΩ 2W
R 8 = 100 Ω 2W
R 9 = 1,0 ΚΩ ½W
R 10 = 1,0 ΚΩ ½W
R 11 = 47 ΚΩ ¼W
R 12 = 100 Ω ½W
R 13 = 100 Ω ½W
R 14 = 27 Ω ½W
R 15 = 47 ΚΩ ¼W
R 16 = 180 Ω ¼W
R 17 = 470 Ω ¼W
R 18 = 15 Ω 2W
R 19 = 56 ΚΩ ¼W
R 20 = 22 KΩ ¼W
R 21 = 4,7 ΚΩ ¼W
R 22 = 2,2 ΚΩ ¼W
R 23 = 2,2 ΚΩ ¼W
R 24 = 12 ΚΩ ¼W
R 25 = 680 Ω ¼W
R 33 = 47 Ω 5W
P 1 = Potentiometer 4,7 ΚΩ
