RM KLV 200 - List of Components

Mod KLV 200 3.10
date 17-12-2001 Page 2 di 2
List of components
C 1 = 27 pF 50 V N750
C 2 = 8,2 pF 50 V N750
C 3 = 10 µF 16 V
C 4 = 47 µF 16 V
C 5 = 82 pF 50 V N750
C 6 = 150 pF 50 V N750
C 7 = 220 pF 50 V N750
C 8 = 150 pF 500 V N750
C 9 = 100 nF 50 V
C 10 = 2 x 6,8 nF 1000 V
C 11 = Variable condensator 30 pF
C 12 =
C 13 = 100 nF 50 V
C 14 = 100 nF 50 V
C 15 = 33 pF 50 V N750
C 16 = 2,2 pF 50 V N750
C 17 = 470 µF 16 V
C 18 = 22 nF 1000 V Polyester
C 19 = 100 µF 450 V
C 20 =
C 21 =
C 22 = 100 µF 450 V
C 23 = 220 µF 16 V
C 24 = 220 µF 16 V
C 25 = 22 µF 16 V
C 26 = 10 nF 50 V
C 27 = 22 µF 16 V
C 28 = 10 nF 50 V
C 29 = 100 nF 63 V polyester
C 30 = 27 pF 50 V N750
C 31 = 27 pF 50 V N750
C 32 = 10 nF 50 V
C 33 = 3,3 pF 50 V N750
C 34 = 100 nF 50 V
R 1 = 1,0 KΩ ¼W
R 2 = 1,0 KΩ ¼W
R 3 = 47 Ω 2W
R 4 = 15 Ω 2W
R 5 = 47 ΚΩ ¼W
R 6 = Trimmer 220 ΚΩ
R 7 = 27 Ω ½W
R 8 = 56 ΚΩ ¼W
R 9 = 100 Ω ¼W
R 10 = 10 ΚΩ ¼W
R 11 = 10 ΚΩ ¼W
R 12 = 1,0 ΚΩ ¼W
R 13 = 1,0 ΜΩ ¼W
R 14 = 470 KΩ 2W
D 1 = 1N4148
D 2 = 1N4148
D 3 = 1N4148
D
4 = 1N4004
D 5 = 1N4148
D 6 = 1N4148
D 7 = 1N4004
D 8 = 1N4007
D
9 = 1N4007
D 10 = 1N4004
D 11 = 1N4004
D 12 = 1N4148
D 13 = 1N4148
D
14 = 1N4148
D 15 = 1N4148
Tr1 = BC 547
Tr2 = BC 547
Ic1 = LM 78L05
Ic2 = PIC 12C508A
Xtal = 4,0 MHz
V = EL 509 - EL 519
L 1 = 7 turns φ 8 mm wire φ 0.8 mm
L 2 = 9 turns φ 8 mm wire φ 0.8 mm
L 3 = 3 turns φ 6 mm wire φ 0.8 mm
L 4 = 13 turns φ 13 mm wire φ 1.5 mm tap 4ª turns
L 5 = RF impedance block
Rl = Relè 6 V 5513
Fuse = 4 A
Lamp 1 = 24 V
Lamp 2 = Meter lamp
S 1 = Switch 3A (St. By - ON)
S 2 = Switch 3A (AM - SSB)
S 3 = Switch 3A (HI - LOW)
S 4 = Switch 3A (ON - OFF)
T = Transformator IN 110 OUT 0-300 V 0-6 V
Fan = Fan 12 V
