model band i_code qty i_descript location
A-01
CDX82A-45W8 A-01 002-04453-F61 1,00 I.C. BH4453F "HEAD PHONE AM
P
IC301
CDX82A-45W8 A-01 002-0DRAM-040 1,00 I.C. Re-used (4Megx4 Dram)
4
IC401
CDX82A-45W8 A-01 004-3-003 4,00 CHOCK COIL 3T 4/CE LCE3,4
,
CDX82A-45W8 A-01 004-3-003A 2,00 CHOCK COIL 3T 2-7 UH 3.5x1.
3
2/CE LCE2,6
CDX82A-45W8 A-01 004-3-100 3,00 CHOCK COIL 10 UH +/-10% L101,103,60
2
CDX82A-45W8 A-01 004-4-100 1,00 CHOCK COIL 100 UH +/-10% @=
4
L501
CDX82A-45W8 A-01 004-4-330 1,00 CHOCK COIL 330 UH +/-10% 4x
5
L603
CDX82A-45W8 A-01 004-65-220 1,00 CHOCK COIL 22 UHx2 @6.5 TC0
5
1/CE LCE1
CDX82A-45W8 A-01 004-DDC-1 1,00 INDUCTORS 130 UH D.D.CON TR
A
L601
CDX82A-45W8 A-01 012-C1077-001 9,00 ELECT. CAP. MINI 100 MFD 6.
3
C101,102,10
4
CDX82A-45W8 A-01 012-C2277-001 2,00 ELECT. CAP. MINI 220 MFD 6.
3
C609,616
CDX82A-45W8 A-01 012-C4758-003 5,00 ELECT. CAP. MINI 4.7 MFD 16
V
C118,307,30
8
CDX82A-45W8 A-01 012-G1067-002 1,00 TAIWAN ELECT CAP. 10 MFD 6.
3
C611
CDX82A-45W8 A-01 012-G2277-001 4,00 TAIWAN ELECT CAP. 220 MFD 4
V
C317,318,32
2
CDX82A-45W8 A-01 012-G2277-002 1,00 TAIWAN ELECT CAP. 220 MFD 1
0
C602
CDX82A-45W8 A-01 012-G3358-004 1,00 TAIMAN ELECT CAP. 3.3 MFD 2
5
C113
CDX82A-45W8 A-01 012-G4758-003 2,00 TAIWAN ELECT CAP. 4.7 MFD 1
6
C311,312
CDX82A-45W8 A-01 012-G4767-001 1,00 TAIWAN ELECT CAP. 47 MFD 4V C323
CDX82A-45W8 A-01 021-5818 4,00 DIODE IN5818 DO-41 D151,602,60
5
CDX82A-45W8 A-01 021-Z0039 1,00 DIODE ZENER 3.9V 1/2W D603
CDX82A-45W8 A-01 029-0628 6,00 TACT SWITCH TS-00100A <01>
6
K2,3,4,5,6,
7
CDX82A-45W8 A-01 029-1132L 1,00 DETECTOR SWITCH DS-20(SS)/M
D
SW512
CDX82A-45W8 A-01 029-1143 2,00 SLIDE SWITCH MSH-12N04 SW301,501
CDX82A-45W8 A-01 030-1035B 1,00 HEADPHONE JACK HST1715-01-1
1
JK301
CDX82A-45W8 A-01 030-1035G 1,00 HEADPHONE JACK HST1715-01-1
1
JK302
CDX82A-45W8 A-01 030-1040A 1,00 DC POWER JACK DS-313-053H @
1
JK601
CDX82A-45W8 A-01 036-06S-P1.5 1,00 Connector 6 Pin Socket (Pit
c
CN601
CDX82A-45W8 A-01 036-16SB-P1 1,00 Connector 16 Pin Socket (Pi
t
CN101
CDX82A-45W8 A-01 083-UL30BK 1,00 Jumper Wire (UL1007#26) 30m
m
1/BT
CDX82A-45W8 A-01 083-UL30R 1,00 Jumper Wire (UL1007#26) 30m
m
1/BT
CDX82A-45W8 A-01 083-UL95BK 1,00 Jumper Wire (UL1007#26) 95mm BLACK
CDX82A-45W8 A-01 083-UL95R 1,00 Jumper Wire (UL1007#26) 95mm RED
CDX82A-45W8 A-01 083-UL95W 1,00 Jumper Wire (UL1007#26) 95mm White
CDX82A-45W8 A-01 029-0621 1,00 TACT SWITCH TS-00104 A (6X6
X
K1
CDX82A-45W8 A-01 003-00882-0A1 3,00 TRANSISTOR HSD882S TO-92 Q601,602,60
3
CDX82A-45W8 A-01 024-16.934MHz 1,00 RESONATOR CERAMIC 16.934MHZ X101
CDX82A-45W8 A-01 002-06575-F61 1,00 I.C. BH6575FV "DRIVER" IC601
CDX82A-45W8 A-01 002-09534-K63 1,00 I.C. BU9534KV "RF+DSP+RAM C
O
IC101
CDX82A-45W8 A-01 027-159 1,00 VOLUME RA1010H-1V-3T@16-A103-B
CDX82A-45W8 A-01 002-24590-W63 1,00 I.C. BU24590-8W "CPU" IC501
CDX82A-45W8 A-01 012-G3377-002 1,00 TAIWAN ELECT CAP. 330 MFD 1
0
C127
CDX82A-45W8 A-01 012-G4777-000 1,00 TAIWAN ELECT CAP. 470 MFD 4
V
C133
CDX82A-45W8 A-01 009-19-030-P1 1,00 HEATSEAL CONNECTOR 19 PIN x 30MM PITCH=
1
CDX82A-45W8 A-01 006-CDX82A-02 1,00 LCD DISPLAY CDX82A-45W8 43x12x2.05mm
A-02
CDX82A-45W8 A-02 003-00114-135 5,00 CHIP TRANSISTOR DTC114TE Q303,304,31
3
CDX82A-45W8 A-02 003-00124-036 2,00 CHIP TRANSISTOR DTA124EKA Q102,301
CDX82A-45W8 A-02 003-01015-099 1,00 CHIP TRANSISTOR HMBT1015 Q101
CDX82A-45W8 A-02 005-S010B-013 1,00 CHIP RESISTOR 1 OHM (0603)
+
R321
CDX82A-45W8 A-02 005-S047B-013 3,00 CHIP RESISTOR 4.7OHM (0603) R100,102,10
5
CDX82A-45W8 A-02 005-S102B-013 4,00 CHIP RESISTOR 1 K (0603) +/
-
R104,317,31
8
CDX82A-45W8 A-02 005-S103B-013 11,00 CHIP RESISTOR 10 K (0603) +
/
R123,501,50
6
CDX82A-45W8 A-02 005-S205B-013 1,00 CHIP RESISTOR 2 M OHM (0603)R143
CDX82A-45W8 A-02 005-S223B-013 5,00 CHIP RESISTOR 22K (0603) +/
-
R106,108,51
4
CDX82A-45W8 A-02 005-S242B-013 2,00 CHIP RESISTOR 2.4 K (0603)
+
R313,314
CDX82A-45W8 A-02 005-S243B-013 1,00 CHIP RESISTOR 24K (0603) +/
-
R617
CDX82A-45W8 A-02 005-S273B-013 1,00 CHIP RESISTOR 27K (0603) +/
-
R606
CDX82A-45W8 A-02 005-S473B-013 2,00 CHIP RESISTOR 47K (0603) +/
-
R323,149
CDX82A-45W8 A-02 016-S1015-006 1,00 CHIP CAPACITOR 100 PF 50V (
0
C112
CDX82A-45W8 A-02 016-S1026-006 1,00 CHIP CAPACITOR 0.001UF 50V
(
C608
