EnglishEnglish
3 4
3. DIR-UP/ASP MP3: select the file search function by Directory (UP):
Anti-Shock Protection on/off
4. Display Window LCD function display
5. Battery Compartment Install Battery
6. PLAY/PAUSE Turns the set on, starts and interrupts CD play
7. SKIP+/SEARCH Skip or fast search tracks forward, and MP3 file
SEARCH-RIGHT
8. CD Door Lift to place the disc
9. STOP Stops CD play, erases a program and turns the set off,
and MP3 file SEARCH-DOWN
10. SKIP-/SEARCH Skip or fast search tracks backward, and MP3 file
SEARCH-LEFT
11. PHONE JACK 3.5mm earphone jack
12. BBS Bass Boost System (ON/OFF)
13. VOLUME Adjusts the volume
14. + Button to enable / disable the Volume limitation
15. OPEN SWITCH Opens the CD lid
16. Recharge Switch Set the switch to ON position to start charging.
POWERSUPPLY
Use with regular batteries
1. Open the battery compartment door, located on the bottom of the unit, by sliding the door
and lift it up. (Do not remove the battery door).
2. Insert 2 x 1.5V /UM-3/AA size alkaline batteries, following the correct polarity, as indicated
in the battery compartment.
3. Close the battery compartment door.
Note: If the symbol “ LOW BATTERY“ appears in the display, batteries are weak and ought
to be replaced.
Usewith AC/DC adaptor(included)
1. Insert the DC plug, at the end of the AC/DC adaptor cord, into the DC 4.5 V INPUT socket
(1) located on the back of the unit.
2. Connect the AC/DC adaptor into a 230V ~ 50Hz AC power outlet.
Notes:
• If the AC adaptor is connected when regular batteries are installed, the power supply
automatically switches to the AC power source.
• Use only the supplied AC/DCadaptor. Using other types ofadaptor maydamage theunit.
• Make sure that the AC/DC adaptormatches with your household voltage before connect-
ing it into the wall outlet.
• When not using AC power, disconnect the AC/DC adaptor from the wall outlet.
• Do not touch the AC/DC adaptor with wet hands.
Use rechargeable batteries
1. Disconnect the AC/DC adaptor from the wall outlet if it is being connected to the unit.
2. Open the battery compartment door as mentioned previously.
3. Insert 2 recommended rechargeable batteries, following the correct polarity as indicated
in the battery compartment.
4. Close the battery compartment door.
5. Move the RECHARGE SWITCH (16) to ON to start recharging function. The red CHARGE
indicator (17) will light up.
6. After 15 hours of charging set the RECHARGE SWITCH (16) to OFF.
Cautions:
• DO NOT mix the rechargeable (Nickel-Cadmium) and regular(Carbon-zinc) batteries.
• DO NOT charge continuously for 24 hours or more, otherwise it will deteriorate the
performance of the rechargeable batteries.
• DO NOT try to recharge normal (not rechargeable) batteries. They can explode!
Notes:
• If the rechargeable batteries are being charged for the first time, it will take approximately
15 hours to be fully charged.
• If the operating time decreases drastically even when the rechargeable batteries are
properly recharged, purchase a new set of rechargeable batteries.
EARPHONES
Connect the stereo earphones (included) to the Phones jack (11).
PCD-495MP_EN.pmd 05/11/2013, 18.362
Both batteries must be of rechargeable NICKEL-
CADMIUMtype.
17. Recharge LED The Red LED indicator will illuminate to slow that
charging is taking place
