not write on the label side of the disc with a ball/point pen as this may scratch the disc.
SPECIFICATIONS
Audio
D/A conversion 1-bit DAC , 8 times oversampling
Frequency response 20-20,000Hz
Anti-shock 45 seconds CD/ 120 seconds MP3 memory
Wow and flutter Below measurable limits
No. of channels 2 channels (stereo)
Output level Line output: 0.6V rms (47KOhm )
Headphone: 20mW (32Ohm)
MP3
MPEG Rate 32-384 Kbps
Sampling Frequency 8/48KHz
MP3 Playback ISO9660 format compatible
Check the CD burner/recorder’s documentation to see if it complies with these specifications.
General
Power requirements -2 x LR6 / UM-3 / “AA” alkaline battery
- DC in 4.5V jack accepts AC power adaptor
(centre positive)
Power consumption 0.8W (DC 3V)
Dimension Approx. 143mm of diameter X 24mm (D)
Weight (without batteries) 210 g.
Note: Specifications and the design are subject to possible modifications without notice.
