HOWTO: Monitor Panel
88
© 2015 by Roadtrek, Inc.
There is a shore power indicator light to the right of the switch to tell you the system is receiving shore power. There is also a
battery charging indicator light to tell you when the batteries are being charged by shore power.
Your refrigerator will run on either 12 volt battery power or 120 volt inverter power, but will use less electricity if the inverter
switch is off because of the conversion loss. If all you're running is your refrigerator, turn the inverter off.
Patio Light
On the control panel, the top left switch is the patio light switch. Press the top of the button to turn the lights on, and the
bottom to turn them off. These are LED lights and use very little power.
Patio light switch Water pump switch with standard
inverter
Water pump switch with 2500 watt
inverter
