Knurled Nuts
Use the knurled nuts to tighten
the jacks on the front panel.
When everything is screwed
tight and all components are
aligned, you can solder the
sockets, the trimmers and the
potentiometer.
11
Header 7
Unscrew the nuts and remove
the front panel. If you want you
can now clean the back of your
PCB. Then solder the three
headers to the PCB.
12
To Next Page
