Robin PROLINE - ProLine connection

REL_CC
REL_NO
BR/W
BL/W
GR/W
REL_CC
REL_NO
REL_CC
REL_CC REL_NO BR BR/W GR BL/W BL GR/W OR OR/W
1 OR / W
2 OR
3 GR /W
4 BL
5 BL / W
6 GR
7 BR / W
8 BR
9 REL_NO
10 REL_CC
REL_CC
REL_NO
BR
BR/W
GR
BL/W
BL
GR/W
OR
OR/W
REL_CC
REL_NO
BR
BR/W
GR
BL/W
BL
GR/W
OR
OR/W



MAC FF : FF : FF : FF : FF : FF
CAT5
MIN
22
3
Max 24V - 0,75 A
Max 24V - 0.75 A
Máx. 24 V - 0,75 A
1
3
2
ProLine connection / Aansluiting ProLine / Anschluss ProLine / Connection ProLine / Conexión ProLine
