Installation Instructions
Secure the product in place
With suitable fasteners, fix the mounting brackets to the cabinetry.
Install the kick plate
1. Prepare a kick plate as shown.
(The mounting hole position is measured by the machine at the factory state. If the height of the
feet is adjusted, the position of the mounting hole should be changed according to the actual
situation.)
2. Set the insertion length of the kick plate and bend the bracket teeth with pliers.
To Next Page
