12
2.2 Main structure of the product
Figure 2.2.1
2.Product introduction
987 mm/38.9 inch640 mm/25.2 inch
770 mm/30.3 inch
932 mm/36.7 inch
932 mm/36.7 inch
500 mm/19.7 inch
1052 mm/41.1 inch640 mm/25.2 inch
855 mm/33.7 inch
956 mm/37.6 inch
956 mm/37.6 inch
525 mm/20.7 inch
Figure 2.2.2
BBR-E60-01/02/05/06
BBR-E60-03/04/07/08
