21
Expanding operation mode: When manually expanding the Electric Wheelchair, please press the
folding switch with one hand (position 1 in Figure 4.2.1.1) and pull the armrest up with the other hand
(position 2 in Figure 4.2.1.1) until the Electric Wheelchair is fully expanded.
4.2 Expanding and folding of the Electric Wheelchair
Remarks: Before folding the Electric Wheelchair, empty the items
in the storage basket to prevent damage.
2
Figure 4.2.1.1
Figure 4.2.1.2
Folding operation mode: When manually folding the Electric Wheelchair, please press the folding
switch with one hand (position 1 in Figure 4.2.1.2) and pull the armrest up with the other hand (position
2 in Figure 4.2.1.2) until the Electric Wheelchair is fully folded.
4.2.1 Expanding and folding operation mode
4.Use of the Electric Wheelchair
1
1
2
