4.5 Left and right handrails
4.5.1 Interchangeable operation mode of left and right armrest controllers
Figure 4.5.1
Step 1, please turn off the machine power before exchanging the left and right
armrest controllers.
Step 2, use a hex wrench to remove the three Allen screws under the armrest
controller and open the connecting harness of the left and right controllers.
Step 3, interchange the left and right controllers, connect the harness, insert the
left and right controllers into the armrest controller card slot, and use the hexagon
wrench to lock the hexagon socket screws. (As shown on Figure 4.5.1)
4.Use of the Electric Wheelchair
