Robosoft RBS-24ED - Page 31

RBS-24ED
KEY
NO.
PART
NO.
DESCRIPTION
1 7070412 Screw, #4 - 24 x 1-1/8 in.
2 7117816 Spacer
3 7030713 Switch
4 7077472 Expansion Pin
5 7074123 Screw, #10 14 x 2 in. (5)
6 7199729 Cap
7 7170262 O-ring Seal, 1.1 in. x 1.4 in.
8 7167659 Screen Support
9 7146043 Screen
10 0521829 Flow Plug, .1gpm
11 7095030 Cone - Screen
12 7248007 Nozzle & Venturi, with Gasket Kit
- 7190547 Gasket (only)
13 1148800 Fill Flow Plug, .3 gpm
14 1202600 Nut-Ferrule
15 7081104 Nozzle & Venturi Housing
16 7081201 Retainer
17 7081764 Seal (Nozzle & Venturi)
18 7170319 O-ring Seal, 1/4 in. x 3/8 in. (2)
19 7082053 Valve Body
20 7129889 Spring
21 7092642 Plug (Drain Seal)
22 7170204 O-ring Seal, 3/8 in. x 9/16 in.
23 7134224 Rotor Seal / Wear Strip
24 7170246 O-ring Seal, 3-3/8 in. x 3-5/8 in.
25 7199232 Rotor & Disc
26 7082087 Wave Washer
27 7170212 O-ring Seal, 3/4 in. x 15/16 in.
28 7170238 O-ring Seal, 7/16 in. x 5/8 in.
29 7085263 Valve Cover
KEY
NO.
PART
NO.
DESCRIPTION
30 7170327 O-ring Seal, 5/8 in. x 13/16 in.
31 0900431 Hose Clamp
32 7024160 Drain Hose Adaptor
33 7142942 Clip
34 0501228 Flow Plug, Backwash / F. Rinse control
35 7113927 Cam and Gear
36 0503288 Bearing
37 7231385 Motor Plate
38 0900857 Screw, #6 - 20 x 3/8 in. (2)
39 7228544 Motor - Includes Key No. 40
40 7224087 Screw, #6 - 20 x 7/8 in. (2)
41 7133498 O-ring (2)
42 7116713 Clip (2)
43 7246568 Sensor Housing/Wiring Harness Asm
44 7113040 Turbine and Support Assembly
45 -- Turbine Support
46 -- Turbine
47 0900060 O-ring Seal
