Rockwell Automation Publication 1794-UM061B-EN-P - March 2020 59
Chapter
6
Configure Your Adapter and Digital Modules
on a ControlNet Network
Introduction
This chapter guides you through the steps that are required to configure your
FLEX I/O ControlNet adapter and associated modules on a ControlNet
network using RSNetworx for ControlNet and RSLogix 5000 software.
This chapter describes how a controller controls distributed I/O over
ControlNet. The controller requires a communication module to connect to the
network. Distributed I/O modules require an adapter to connect to the network.
In this example, we show you how to control FLEX I/O over ControlNet using
RSNetworx for ControlNet and RSLogix 5000.
To control distributed I/O over ControlNet, you must:
• Add local and remote ControlNet communication modules to your
RSLogix 5000 project.
• Add distributed I/O to your RSLogix 5000 project.
• Schedule the ControlNet network via RSNetWorx for ControlNet.
• Use the I/O information in RSLogix 5000
You can also validate connections to distributed I/O when controlling it over
ControlNet. This task is useful when one or more of the connections are not
working but is not required, especially when all connections appear to work
normally.
For this information: See page:
Set Up the Hardware 60
Setting a Requested Packet Interval (RPI) 60
Select a Communication Format 61
Add Local and Remote ControlNet Modules 67
Add Distributed I/O 68
Download the Program to the Controller 70
Configure the 1794-ACN15 Adapter 71
Schedule I/O Module Connections 72
Access Module Data via the 1794-ACN15 Adapter 77
Change Configuration Data 79
